Flat-Pack Raised Garden Beds
20 mm spruce bed, liner + brackets, one parcel-size carton, ISTA 3A tested, quoted per drawing.
Smaller, higher-margin, and the item that gets a cafe, a hotel and a boutique storefront to order 40 pieces at once. We make them with a floating base so soil weight does not split the ends.




Model TB-BD-620 · HS 4421.99.9780 · Made in Jiangsu, China
We quote from your spec sheet, not from a public list: face profile, species, finish, hardware, packing and order quantity. Send a drawing or a sample and you get a tiered offer with the packing list and CBM per container inside 24 hours.
| Attribute | Standard configuration |
|---|---|
| Window box sizes | 600 / 800 / 1000 mm, 180 × 180 mm internal |
| Trough planter sizes | 800–1500 × 300 × 300 mm (custom to 2400 mm) |
| Boards | 15–18 mm larch, ACQ pine or 12 mm bamboo laminate |
| Base | Floating, slotted, with 0.2 mm LDPE or geotextile liner |
| Drainage | 3–5 slots + liner; reservoir option for hospitality |
| Finish | Oiled, stained, painted (Pantone), charred, or left to grey |
| Hardware | Bracket set (2 pcs) + fixings, load-rated; castor base option |
| Packing | Nested 5 pcs per carton with kraft interleaves, or 1 pc gift box |
| Order quantity | What changes commercially |
|---|---|
| 200–499 | Pine ACQ, kraft box, liner included |
| 500–1,999 | Larch option, brackets packed in, brand label |
| 2,000+ / 40'HQ | Colour-matched finish, retail sleeve + barcode |
Window boxes fail by rotting at the base corner where the liner folds, and by pulling their fixings out of a soft fascia. We cut the base as one floating panel with 8 mm perimeter clearance, use a one-piece LDPE liner welded at the folds, and publish a bracket load rating so your installer specification is defensible.
| Species / board | Where it wins | Watch out for |
|---|---|---|
| Siberian larch | No-treatment premium, tight grain, retail darling | Knots vary; grading adds 6–9 % |
| ACQ pine | Cheapest durable option for DIY price points | Green cast. Sell as 'treated' honestly |
| Laminated bamboo | Modern, straight, no visible knots | Water-laminate edges need a good oil regime |
| Thermally modified ash | Black-brown designer look | Premium price; niche retail only |

Cafes, hotel storefronts, balcony brands and garden centres all order these in runs of 20–80.
Liner declared for vegetable and herb beds; PEVA free of phthalates.
Class 3/4 retention record, or chemical-free thermally modified pine.
Harvest geolocation data on request for your due-diligence statement.
One bed per carton under 25 kg, engineered for carrier networks.
We supply bracket load ratings in writing (a spec sheet, not a promise), liner material declarations, and treatment certificates. For hospitality projects we also supply a fire-retardant coating option with its test report where the venue requires it.
The answers below are the ones we give on the phone. Anything missing, ask on WhatsApp.
No: a welded one-piece LDPE liner plus 8 mm perimeter clearance contains soil and water; we still advise a drip tray SKU for stone and timber facades and we can supply one, powder-coated to match the box colour.
Yes, a 35 mm reservoir with an overflow weep hole and a wicking mat, sold as a hospitality SKU. It adds a modest per-piece cost and lets the trade sell a '4-week holiday' claim; the watering window depends on plant and aspect, and we say so on the insert.
200 pcs per size in a standard colour; Pantone-matched opaque finish at 500 pcs. Larch oiled lines can start at 100 pcs because the finish is a dip, not a spray-booth colour change.
Yes — 5 pcs nested per carton with kraft interleaves, which cuts cube roughly 30 % against single-box packing. We quote both: nested for trade, single gift box for online sellers who cannot re-box on arrival.
20 mm spruce bed, liner + brackets, one parcel-size carton, ISTA 3A tested, quoted per drawing.
Solid pine/poplar, mitre + spline, 3-coat paint, acrylic glazing. MOQ 500 pcs mixed sizes, quoted per drawing.
31 stocked profiles, 15–90 mm face, raw to foil, 2,000 m MOQ, quoted per metre, the repeat-purchase line.
We quote within 24 hours with a spec sheet, tiered FOB, packing list and carton count per container.
